JULIBAO-LK9000 LX PRO

Speed

450rpm(Leno weaving),550rpm(normal weaving)

Fabric width

165cm

Repeats

1 twist 1 to 1 twist 10

Weft density

Electronic density adjustment from 5-150 picks/cm,1-4picks/cm,150-200picks/cm(as option)

Weft selector

8 colors(12 colors as option)

Contorller

Electronic system with microprocessor

Warp let-off

Electronic let-off motion with tension device

Stop motion

Electronic,machine stops automatically when warp or weft breaks

Take up

Electronic

Weft fonding

Automatic weft pick finding whet variable program

Lubriciation

Centrailzed lubrication system

Warp beam

Double beams, diameter of 800mm

Jacquard

STAUBLI LX PRO

Hooks

7680/10240/12288 Hooks

Controller

TC 8 Controller

Harness kit

Italy RTS harness cord

Germany Hornex harness board

Customized leno heddles

Weft feeder

IRO Star G2/Laser G2/Chrono X3

Dimension

W5300mm/L3100mm/H4100mm

Weight

Approx 7000kg

Power supply

3 phase，380V，50HZ，±10% tolerance

Power

Start at 15kw，running at 9-10kw
